Conveyor Max Load(kgs)100
Unit size2386(L)*1357(W)*1345.5(H) mm
PenetrationTypical 40mm steel, guarantee 38mm steel
Wire ResolutionTypical AWG40, guarantee AWG38
X-Ray generator2* 160KV, oil cooling, one from bottom to top, one from left to right
Image Enhancement1-64times enlargement continuity, Color/BW, negative,high/lowpenetration, organic /inorganic
Stripping, general enhancement, and pseudo color,etc.
Image ArchiveUp to 50,000 images stored automatically, enable transferring to USB disk, and converting to JPG, BMP, XF, PNG, TIFF, GIF six formats.
Other FunctionsTime/date display, counters, user management, system-on/X-ray-on timers, power on self test,built-in diagnostic facilities, dual-direction scanning, system log, system standby and stimulant training, ADS etc.
* Multilingual operation* Automatic built in test and self diagnosis
* Secure access Key* Continuous working 10000 hours above
* Threat alert and material classification
* International standard configurationJapan Hammatsu detection and UK Sens-tech board
* NetworkReady* Energy saving design
* One key turn off* Drugs and explosives inspection
* Indication of the date and time
