Super quality MD200A body security handheld detector,metal detector

I'm Online Chat Now

Super quality MD200A body security handheld detector,metal detector

Super quality MD200A body security handheld detector,metal detector
Super quality MD200A body security handheld detector,metal detector Super quality MD200A body security handheld detector,metal detector

Large Image :  Super quality MD200A body security handheld detector,metal detector

Product Details:
Place of Origin: Guangdong, China
Brand Name: sunleader
Certification: CE/ROHS/ISO9001
Model Number: XLD-MD200A
Payment & Shipping Terms:
Price: $8.00 - $10.00/sets
Packaging Details: oem packing or customized
Supply Ability: 10000 Unit/Units per Month
Detailed Product Description
Warranty: 2 Years Usage: Security Check
Type: Hand Hold Sensitivity: High
Color: Black Name: Handhold Metal Detector
Application: Gold Prospecting Power: 2 Pcs 9V Batter
Keyword: Metaldetector Port: Shenzhen

Super quality MD200A body security handheld detector,metal detector

Super quality MD200A body security handheld detector,metal detectorSuper quality MD200A body security handheld detector,metal detectorSuper quality MD200A body security handheld detector,metal detectorSuper quality MD200A body security handheld detector,metal detector



1. Product parameter

Model: XLD-MD200A

Size: 420mm(Length)*138mm(Width)*110mm(Height)

Handle measurement: 30x30mm

Operating Frequency: 20Khz

Battery: A 9V battery ( it can be used for 40 hours normally)

Indicator: BZ, vibration motor

Control: three-position switch (ON,OFF, a sound of light mode of vibration)

Weight: 272g (including batter)



The MD-200 hand held metal detector is fit for the security detecting of the airports and bus stations and docks and customs inspections and police security detections and border detections and so on; it is fit for the quality detection of medicines and commercial system; and it's fit for the precious metals detecting and it's fit for the security detection of stadiums and entertainments.



2. Features

Use circle switches to change sound alarm and hide vibrating alarm respectively. It has a high sensitivity and it can detect ferrous metal and non-ferrous metal. It has simple and convenient use and easy regulation.

When find metal objects it will give a sound (or vibration) and light alarm. Alkaline batteries could work with a 10%15% alarming rate and they could continuously work for 40 hours.

When the voltage of the batteries changed from 9v to 7v, the detecting distance won't change. When the voltage is very low it will alarm continuously automatically.



3. Detecting distance

Metals:

Pin: 10mm

64-style pistol: 150mm

6 inch dagger: 150mm

Steel ball with 8mm dia.: 40mm

Non-ferrous metals:

10mm*5mm*0.08mm Al/copper: 10mm

DIP14IC: 5mm

1 g silver ring: 40mm

1g plumbum: 30mm



4. Operation:

1. Press the power switch, there is a turn-on sound (or vibration indication). If the green light is on that means the power is on and it can detect. In detecting, hold the detector to detect around the objects. If there are metals the light will change to red automatically and give a sound at the same time (or give a vibration). The sound (or vibration) stops when stop detecting or the green light will be lightened.

2. Press the power switch and there is a indicating sound or vibration. If the green light is off that means the power is off.

3. When the sensitivity has been regulated a little high, there will be a 3~4s sound or vibration that is a normal phenomenon. It could be used after scanning metals with it.



5. Regulating the sensitivity

1. Regulate its sensitivity when it's not stable because the detecting distance cannot achieve the standards or it alarms for human bodies.

Method: hold the detector and unscrew the screws of batteries covers. And flatly pull the cover back gently.

2. When the power is on, adjust the potentiometer screws on the circuit board in front of the batteries with screwdriver. Adjust it to just give a sound and then counterclockwise turn it half or a whole circle until it stops giving a sound. The sensitivity will be increased if you clockwise adjust it and the sensitivity will be reduced if you counterclockwise adjust it. After the adjusting, move the batteries cover flatly and tighten the screws.
