Airport usage 30mm penetration high resolution X-ray baggage Mahine for luggage inspection

I'm Online Chat Now

Airport usage 30mm penetration high resolution X-ray baggage Mahine for luggage inspection

Airport usage 30mm penetration high resolution X-ray baggage Mahine for luggage inspection
Airport usage 30mm penetration high resolution X-ray baggage Mahine for luggage inspection Airport usage 30mm penetration high resolution X-ray baggage Mahine for luggage inspection Airport usage 30mm penetration high resolution X-ray baggage Mahine for luggage inspection Airport usage 30mm penetration high resolution X-ray baggage Mahine for luggage inspection Airport usage 30mm penetration high resolution X-ray baggage Mahine for luggage inspection Airport usage 30mm penetration high resolution X-ray baggage Mahine for luggage inspection

Large Image :  Airport usage 30mm penetration high resolution X-ray baggage Mahine for luggage inspection

Product Details:
Place of Origin: Guangdong, China
Brand Name: SUNLEADER
Model Number: XLD-10080
Payment & Shipping Terms:
Price: $13,000.00 - $14,000.00/sets
Packaging Details: 8CBM. 900KG
Supply Ability: 2000 Roll/Rolls per Month
Detailed Product Description
Tunnel Size: 1000w X 800h (mm) Conveyor Speed: 0.22 M/s 1
Conveyor Max Load: 200 Kg Steel Penetration: 30mm Armor Plate
Port: SHENZHEN

Airport usage 30mm penetration high resolution X-ray baggage Mahine for luggage inspection

Airport usage 30mm penetration high resolution X-ray baggage Mahine for luggage inspection



Product Parameters:

 General Specification

Tunnel Size

1000(W)*800(H)mm

Conveyor Speed

0.22m/s

Conveyor Max Load

200kg

Dose per Inspection

<1.7uGy/h

Resolution

<0.101mmMetal Wire

Spatial resolution Level

diaφ1.3mm , Vertical:diaφ1.0mm

Through resolution

φ0.254mm

Penetration

30mm Steel

Film Safety

Guarantee ISO1600 Film

X-ray Leakage

0.1 uGy/h (at a distance of 5cmFrom external housing)



 X-ray Generator

Generate direct

Downward

Generate angle

80 degree

Anode Voltage

100~160Kv

Anode power

0.4 to 1.2mA

Cooling / Duty Cycle

Oil Cooling /100%



 Installation Data

Operating Temperature

0℃~45℃

Operating Humidity

20%-95%(non-condensing)

Storage Temperature

-26℃~60℃

Storage Humidity

20%-95%(non-condensing)

Operation Power

220AVC/(±10)50Hz±3Hz

Power Consumption

1.0KW(Max)

Noise

<65 dB



Feature and Application:

X-ray penetrate inspection, the object can be found within the metal structure, can display the

naked eye can not see where the liquid is also very obvious object display.Used in the factory

testing of security products and business units such as: electronic factories, shoe factories,

toy factories, courts, railway stations, and event bag, line security management package

 Airport usage 30mm penetration high resolution X-ray baggage Mahine for luggage inspection

1. Are you manufacturer or trading company?

We are ISO9001 verified manufacturer of SECURITY and Safty products who has over 10 years' experience.

2. What is the minimum order quantity?
The MOQ is 1 set.
3. What is the lead time?
3-5days after T/T payment, for other products please contact us for details.
4. What is the payment term?
The payment term is T/T ,L/C before shipment.
5: How does your company and factory do regarding quality control?
Every products will be detected after producing and approved by ISO9001 certificate.

6. How can I get in touch with you?

Please see below!

 Airport usage 30mm penetration high resolution X-ray baggage Mahine for luggage inspection
