|Tunnel Size:||650(W)x500(H) Mm||Conveyor Speed:||0.1m/s|
|Conveyor Max Load:||100kg||Resolution:||Diameter Of 0.1mm Metal Wire|
|Penetration:||30mm Steel Plate||Storage Temperature:||-20°C To 60°C|
|Operating Temperature:||0 °C To 45 °C||System Power:||220VAC (±10%) 50±3HZ|
|Power Wastage:||1.0KW(max)||Name:||Security Equipment|
Conveyor max load:
Single inspection dosage:
0.1mm metal line
30mm armor plate
for ISO 1600
Maximum leakage radiation:
-20°C to 60°C
0 °C to 45 °C
20 to 95% non-condensing
220VAC (±10%) 50±3HZ
Image performance system
X-ray sensor: 1 Type photo-diode array detector, 12bit
Monitor: High resolution 17inch color led display
Color quality: 24 bit real colors
Edge enhancement: object contour edge is more distinct
Super image enhancement: image detail is more distinct
High penetrate strength display: increase brightness of dark area in image to diplay object which is behind high absorption mass distinctly
Low penetrate strength display: increase brightness of image/decrease brightness of image
Image recurrence: display previous twenty images and process any one of them
Image restoration: restore image to initial status at the time of stopping conveyor
Image storing: real time store any image and process it in operation status
Multienergy color: display organic material for orange, display inorganic material for blue, and display mixture for green
High enery/low energy: switch to display tow energy type, high energy stands for metal etc, low energy stands for non metallic
Auxilitay function for drugs &explosives: help to detect such dangerous material as drugs&explosives ect
Audible&visible alarm: give sound and visible signal when confirming to condition
Alarm by sounds&light: Alarm by sound and light when confirm to condition
Network interface: It can connect to local area network and support multi-terminal check baggage at same time.
Safty ray: Transmit ray under automatic control, avoiding any baggage missing.
Image monitoring for userfriendly: The monitor use fold, rotary system, operators, adjusts the monitor position willfully according to our own need, reduce wearily.
Simple operation by mouse: Without keyboard and work table, control by mouse, save space.
Turn off a key control: Turn off the machine only need one step, revolove the key then the equipment automatic secuirty close down and no need complex steps.
Eagle-eye: It can be expediently observing enlarged area.
Estimate malfunction by self: Automatic estimate malfunction and prompt message, helpful for maintenance
